Description

what is it ?

New Holland Electronic Service Tools (EST) 9.11 or 9.12 is a professional electronic diagnostic and maintenance tool software provided by New Holland agricultural machinery brand for its equipment. As a brand of CNH Industrial, New Holland’s EST software is designed to help technicians, dealers or farmers connect to the electronic control unit (ECU) of agricultural machinery through a computer to perform fault diagnosis, parameter configuration, firmware upgrade and other operations.

Attention ：
Please send us team viewer id with password after the payment of your order , our engineer will help you install and activate software remotely (only one time free on one laptop )

Teamviewer full version download link:  https://www.teamviewer.com/en/download/windows

Features:

Version: v9.11/v9.12
Update: 03.2025

region: All regions
Type: Diagnostic Software For Case, New Holland
Languages: English, Italian, Russian, Polish, Spanish, French, Portuguese, German, Dutch, Danish.
OS: Windows 10 64 bit, except Home editions, WIN 11
The brand new version of New Holland CNH EST works with OS Windows 10 64 bit, except Home edition).

NOTE: one only pc intallation (Activation by teamviewer)

EST 9.12.0.0 New Features

The release of the Electronic Service Tool (EST) 9.12.0.0 and eTIM updates include several improvements to the service tool software. These changes include:

• Windows 10 support update*
• Support for Utility tractors with “O” in PIN
• Engine Dataset search enabled when ECU Offline
• New IFM Vision Assistant Version Support (New Holland AG only)
• New Vehicle Support



Core Features

1 ,Fault diagnosis and reading:

Connect the CAN bus or diagnostic interface of the agricultural machinery through the adapter, read the fault code (DTC), and provide detailed fault description and maintenance suggestions. Support real-time monitoring of equipment operation data (such as engine speed, hydraulic pressure, temperature, etc.).



2,Parameter Configuration and Calibration:

Adjust equipment control parameters (such as engine power, transmission settings, hydraulic system thresholds, etc.). Calibrate sensors or actuators (such as GPS navigation systems, planter metering units, etc.).



3,Firmware and Software Updates:

Upgrade the latest firmware for ECUs, displays, or other electronic modules to fix known issues or improve performance.



The software EST v9.10 comes as:

• CNH EST 9.10.0.0.1 installation file,
• CNH EST 9.10.0.0.2 (EST91000Up1) update,
• Controller Package v134 (02/2024),
• EASY Software installation package v18.1.1.0  (E.A.S.y – additional engine diagnostic and download tool for connection directly to ECU to perform diagnostic, programming and ECU reload by K-Line protocol),
• New Legacy Diagnostics database for Troubleshooting,
• Activation for a single computer
• Teamviewer remote assistance with setup & activation



CNH EST 9.9 Electronic Service Tool allows you to:
• Check status of parameters;
• Retrieve faults;
• Run diagnostic tests;
• Make ECU and parameter programming;
• Monitor active and logged diagnostics;
• View and change ECU configuration;
• View diagnostic procedures and schematics.
• Troubleshoot problems;
• Use assist database;
• Run scope diagnostics;



CNH EST 9.9 New Features

The release of the Electronic Service Tool (EST) 9.6.0.0 and new eTIM software includes several

improvements to the service tool software. These changes include:

– EST PC Operating System (OS) and hardware requirements

– EST Software Installation and licensing

– EST Update tool / eTIM GO without EST installation

– EST Update tool Security Updates

– New diagnostic adapter support

– EEPROM Dumper tool (New Holland AG only)

– EASy database function

– Legacy Diagnostics download and installation
